360 Point Vortex Coil using only 120 Guide Pins

alexalex

After much experimentation, I have devised a way to wrap 360 winds on a small torrid surface. I have done this by using all 120 pins as a single first wind. Then I use the initial winding series as the guide for the second winding series laying the second wire always just to the right of the first. This allows you to create a 360 point coil (120 points of Yin, Yang, and Boundary) without hitting the physical space limitation for guide pins! This approach allows you to get a maximum of copper on the core surface.

360 Point Vortex Coil

Here is the winding series table for the Vortex coil:

Winding pattern for 360 points Vortex Coil using only 120 guide pins

Here is the Yin winding pattern.

Yin windings for 360 Point Vortex Coil

Now, using the Yin wire as your guide, wind the Yang wire always to the right of the “guide” wire.

Yin and Yang windings for 360 Point Vortex Coil

Coil map indicating boundary flow.


Full flow windings for 360 Point Vortex Coil

Here is a view of the coil after the first winding:

.:.
